Technical specifications

Weight:	50.40 kg
EUROLITE LED IP Mega PIX Strobe 714 SWING
Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	365 W
IP classification:	IP65
Protection class:	Protection class I
Power connection:	Mains input via IP T-Con (M) mounting version power supply cord with safety plug
Cable construction:	3 x 1.5 mm² H07RN-F
Power output:	IP T-Con (F) mounting version
Lamp type:	LED lamp
LED type:	126 x 3 W SMD 3535 cold white (CW) 588 x 0.25 W SMD 5050 4in1 QCL RGBW (homogenous color mix)
Max. TILT movement:	200° positioning auto position correction (feedback)
Flash rate:	0.5 - 17 Hz
Equipment:	Dimmer
DMX channels:	8; 9; 11; 12; 17; 18; 71
DMX input:	3-pin XLR (M) mounting version IP 1 x 5-pin XLR (M) mounting version IP
DMX output:	3-pin XLR (F) mounting version IP 1 x 5-pin XLR (F) mounting version IP
Cooling:	1 x cooling fan at the base 2 x temperature-controlled fan at the head
Control:	DMX; RDM; stand-alone; master/slave function
Fixtures available for:	Light Captain
Projection:	Flicker-free
PWM frequency:	4100 Hz
Beam angle:	120°
Beam angle (1/2 peak):	Matrix effect 120°
Beam angle (1/10 peak):	Matrix effect 170°
Housing color:	Black
Attachment system:	2x omega bracket
Display type:	Multicolor TFT display
Carrying handle:	2 pc/pcs
Transport aid:	4 x rubber feet
Use of brands:	Built with SEETRONIC connector
Material:	Aluminum casting
Dimensions:	Width: 52.5 cm Depth: 14.0 cm Height: 33.5 cm
Weight:	12.85 kg
Noise classification:	Class 2 (slight noise)
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting
ROADINGER Flightcase PRO 2x IP Mega SWING with wheels
Maximum load:	50 kg
Aluminum profile frames:	30 mm
Case handle:	4 pc/pcs
Stop hinge:	2 pc/pcs
Lock:	Butterfly lock: 2 pc/pcs with shut-off function
Transport aid:	2 x castors with 2 locking brakes Ø 100 mm
Material:	Plywood multi-layer glued, 9.5 mm, laminated
Color:	Black
Device compartment:	53 cm x 14.5 cm x 33.5 cm
Accessory compartment:	55 cm x 15 cm x 33.5 cm
Dimensions:	Width: 60 cm Depth: 61.5 cm Height: 61 cm
Weight:	24.70 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397756340	55,00 kg

Spare parts

EUROLITE Omega bracket 61

Pcb (Power Supply) 24V/21A LED IP Mega PIX Strobe 714 Swing (LLC500W-24V)

Pcb (Display/Control) LED IP Mega PIX Strobe 714 Swing

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
20001064-Images-.zip

Video link

https://www.youtube-nocookie.com/embed/LpMvRQguLhY

EUROLITE Set 2x LED IP Mega PIX Strobe 714 SWING + Flightcase with wheels

Stock for approx. 12 wk(s)

1.999,00 €

Find a dealer

Stock for approx. 12 wk(s)

Due to the dimensions of this article, different shipping conditions apply.

List price excl. 19% VAT
Prices in retail stores may vary.

No. 20001064

120° matrix effect

strobe effect

9.5 mm

Set consisting of:

2 x EUROLITE LED IP Mega PIX Strobe 714 SWING

1 x ROADINGER Flightcase PRO 2x IP Mega SWING with wheels

EUROLITE LED IP Mega PIX Strobe 714 SWING

Outdoor spotlight (IP65) with tilt motor for strobe, blinder and matrix effects

126 LEDs 3 W SMD 3535 cold white (CW)
7 segments controlled separately
588 LEDs 0.25 W SMD 5050 4in1 QCL RGBW (homogenous color mix)
14 segments controlled separately
Positioning within 200° TILT
Dimmer
Color macros adjustable; Dimmer electronic; color blend stepless; program speed adjustable; program selection adjustable; color animations with two adjustable colors
Ambient effect; strobe effect; Blinder effect
46 integrated show programs
The device is cooled by cooling fan at the base; temperature-controlled fan at the head
Control via DMX; RDM; stand-alone; master/slave function
Fixtures available for Light Captain
Flicker-free
With a beam angle of 120°
With omega bracket
Multicolor TFT display
2 Rugged carrying handles
4 x rubber feet
Mains input and output for power linking up to 8 units
Built with SEETRONIC connector
Suitable for outdoor use IP65
With pressure compensation membrane
For application areas such as: Stage; clubs/dancing school; wedding/gala/events; rental
Application possibility: Standing; suspended
